1.5~6s RFID Card Long Distance Reading IP 54 Enclosure Rating Vehicle Parking Barrier Gate
Brief description
The product consists of five parts: cabinet cap, cabinet body, transmission mechanism, control unit, and boom. It distinguishes between left and right machines and is used in parking lot entrance and exit control systems.
This product is divided into three types: straight boom barrier, folding boom barrier and fence boom barrier.
Note: If any customization which is not listed in the following table is needed, please consult the marketing staff.
Barrier Types
| Type | Description (Boom length = L, Seconds=S) |
| Barrier Gate with Straight Boom | ・ L<3M, up speed 1.5S. • L<4M, up speed 3S. ・ L<4.5M, up speed 4S. • L<5M, up speed 5S・ L<5.5M, up speed 6S. |
| Barrier Gate with Folding Boom | • L<3M, up speed 3S. ・ L<4M, up speed 4S. •L<5M, up speed 6S. |
| Barrier Gate with Fence Boom | • Two-levels, L<3M, up speed 4S. ■ Two-levels, L<3.5M, up speed 5S. • Two-levels, L<4.5M, up speed 6S. • Three-levels, L<3M, up speed 5S. • Three-levels, L<4M, up speed 6S. |
TECHNICIAL SPECIFICATIONS
| | SN-DZE-BL (speed 1.5-6s adjustable) |
| | | | | | | | | |
| | | | | | |
| | | | | | | | | |
| | AC 220V±10%, AC110V±10%,50/60HZ |
| | |
| | |
| | |
| | |
| Traffic Flow Application | |
| | |
| | |
| | |
Functions & Features
1. Driven by DC brushless motor, equipped with movable connecting rod transmission mechanism and balance spring, stable and reliable operation. Motor life cycle up to 2,500,000 times or more, and spring life cycle up to 500,000 times.
2. Built-in delay auto-closing and reverse on an obstacle in case of resistance.
3. Support infrared photocell, loop detector, and external radar, and built-in DC12V power output.
4. Standard fitting with 433MHZ learning code remote control, convenient and quick to add configuration.
5. When power off, the barrier gate can still work by adding 2 external DC12V batteries. And battery charging module is optional, when power on, the battery will automatically charge.
6. Holes are available to fix the articulated or fence boom, and multiple boom types on one machine can be easily changed.
FAQ
Q1: What are your main products?
A: Its main products include automatic barrier gate, tripod turnstile, flap barrier, swing barrier, etc.
Q2: Are you a manufacturer? Do you provide ODM / OEM service?
A: Yes, we are a manufacturer. WEJOIN provides professional customized services for global clients.
Q3: I would like to ask if this is with the RFID card reader and controller?
A: Yes, there is a controller, our barrier gates can connect with RFID card readers.
Q4: What boom types of your barrier gate?
A: We have 1s with 3m barrier arm, 3s with 4.5m barrier arm, 6s with 6m barrier arm, etc
Q5: What is your MOQ?
A: Any quantity is acceptable.
Q6: How much is 1 set? Can provide product details? How fast and how much it would cost to ship this item?
A: Please Click here and send your inquiry, then we will send you the price and details in time.
Q7: How about the payment option?
A: 30% by T/T, 70% by T/T before delivery.
Q8: Do you have a model that can be used outdoors without further shelter?
A: Yes, It can be used outdoor without shelter. But product life will be longer with shelter.
Q9: How much warranty time do you have?
A: Within one year, if any problems, we will offer the accessories.
Q10: Do you use WeChat? Can we please talk on WeChat? or WhatsApp?
A: Yes, my WeChat ID FZ15002051250, my phone number/WhatsApp is +86 15002051250, my skype ID wejoin09.
